Spax Wood construction screws
50 Screws per piecePrice in EUR including VAT
Delivered between Wed, 7/5 and Fri, 9/5
Only 1 item in stock at supplier
Only 1 item in stock at supplier
Length
- 80 mmEUR45,85
- 100 mmEUR44,79
- 120 mmEUR65,51
- 140 mmEUR63,02
- 160 mmEUR81,05
- 180 mmEUR159,–
- 200 mmEUR110,85
- 220 mmEUR139,–
- 240 mmEUR139,09
- 260 mmEUR159,–
- 280 mmEUR185,46
- 300 mmEUR160,20
Product details
The SPAX typical drive T-STAR plus is a so-called internal hexagon. This shape increases the contact area of our T-STAR plus, allowing the T-STAR plus bits to fit optimally in the screw head. The best possible power transfer from the screwdriver to the screw through T-STAR plus enables quick work, significantly more efficiently than with any other drives.
The countersunk head (or flat countersunk head) mills a recess into the wood with its polygonal underside ("pockets") and can therefore be sunk without the need for additional countersinking of the screw hole. The countersunk head sits flush with the surface.
The screws with partial thread are excellent for fastening thin components such as wood-based panels, boards, or floorboards to thicker components like beams or posts. The short thread screws into the thick component, while the unthreaded shank remains in the attachment component. This creates maximum clamping pressure between the two. The unthreaded part should be at least as thick as the attachment component.
The term 4CUT refers to the square shape of the screw tip. These edges displace the wood fibers during insertion and create space for the screw's core diameter. The spreading pressure that the core exerts in the wood is thus reduced, preventing the wood from splitting near the edge. Additionally, the necessary torque of the cordless screwdriver is reduced, as the core of the screw does not have to "squeeze" into the wood.
The abbreviation A2 in our stainless steel screws comes from the alloy of the steel. Screws made of stainless steel A2 offer high protection against corrosion and medium strengths. Their resistance to seawater and acids is low. Therefore, they are used for outdoor applications in coastal areas.
type of screw | Wood screw |
bolt diameter | 8 mm |
head shape | Countersunk head |
Screw length | 160 mm |
Version | Unique specimen |
Size (D x L) | M8 x 160 |
Item number | 15878648 |
Manufacturer | Spax |
Category | Screws |
Manufacturer no. | 9017708 |
Release date | 24/5/2021 |
External links |
Colour | Silver |
Exact colour description | Silver |
Metal type | Stainless steel |
Material group | Metal |
Material | Stainless steel A2 |
surface finish | A2 |
type of screw | Wood screw |
Version | Unique specimen |
thread type | Partial thread |
head shape | Countersunk head |
impetus | Pin-torx |
Output size | T40 |
Suitable for | Engineered woods |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 4CUT, 50 piece, 8 x 160 mm, A2 stainless steel - 0197000801605, Partial thread, SENKKOPF, Stainless steel screw, T-STAR plus T40 |
Items per sales unit | 50 Screws per piece |
Size (D x L) | M8 x 160 |
bolt diameter | 8 mm |
Screw length | 160 mm |
thread length | 80 mm |
